Colorful Tones, Portable Design

Players everywhere love the GX-100 for its streamlined design, free-flowing interface, and high-quality tones. Armed with the core GX-100 engine, the compact GX-10 brings you the same inspiring experience in an even more portable footprint. You get loads of AIRD amps and effects for covering every style, plus speedy sound building with the intuitive color touch display and panel knobs. Adding in multi-mode footswitches, an integrated expression pedal, and USB audio connectivity, the GX-10 seamlessly transitions from nightly stage performing to desktop recording, song creation, and daily practice sessions.

Standard Features

Compact amp/effects processor for guitar and bass
The same sound engine and color touch display as the GX-100 in a portable, travel-ready design
Exceptional audio quality with 24-bit AD and 32-bit DA conversion, 32-bit floating-point processing, and 48 kHz sampling rate
Authentic tube amplifier tone and touch response with AIRD technology
32 amplifier types and 170 BOSS effects
Ultra-flexible amp/effect routing up to 15 assignable blocks
Wide selection of onboard speaker types and support for loading WAV speaker IRs
Streamlined modern design with a rugged metal chassis
Three footswitches with flexible control modes
Onboard expression pedal with toe switch
Connect up to two footswitches or an expression pedal for expanded control
Send/return loop for external pedals
Record and play tracks in music production software on a computer or mobile device* via a USB-C®
Edit sounds from your computer with BOSS Tone Studio for macOS and Windows
Download and share Livesets at BOSS Tone Exchange (compatible with GX-100 Livesets)
Optional Bluetooth® Audio MIDI Dual Adaptor allows you to edit sounds and stream audio from an iOS or Android mobile device

*Compatibility with all third-party devices and software is not guaranteed.

Specifications
Sampling Frequency: 48 kHz
AD Conversion: 24 bits + AF method
*AF method (Adaptive Focus method) This is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.
DA Conversion: 32 bits
Processing: 32-bit floating point
Effects: 170 Types
Maximum Number of Effects: 15+3 (DIVIDER/MIXER, SEND/RETURN, PHRASE LOOP)
*depending on the circumstances
Memories: 198 (User) + 99 (Preset)
Phrase Loop: 38 sec. (MONO)
19 sec. (STEREO)
Tuner Internal Detection: +/-0.1 cent
Nominal Input Level: INPUT: -10 dBu
RETURN: -10 dBu
Maximum Input Level: INPUT: +7 dBu
RETURN: +7 dBu
Input Impedance: INPUT: 1 M ohm
RETURN: 1 M ohm
Nominal Output Level: OUTPUT (L/MONO, R): -10 dBu
PHONES: -10 dBu
SEND: -10 dBu
Output Impedance: OUTPUT (L/MONO, R): 1 k ohm
PHONES: 44 ohms
SEND: 1 k ohm
Recommended Load Impedance: OUTPUT (L/MONO, R): 10 k ohms or greater
PHONES: 44 ohms or greater
SEND: 10 k ohms or greater
Controls: DOWN switch, UP switch, CTL1 switch, POWER switch, EXP1 switch,
PAGE button, MENU button, EFFECTS button, EXIT button, WRITE button, 1-4 knobs, SELECT knob, OUTPUT LEVEL knob,
EXP1 pedal
Display: Color Graphic LCD (480 x 272 dots) Touch screen
Connectors: INPUT jack, OUTPUT (L/MONO, R) jacks, SEND jack, RETURN jack: 1/4-inch phone type, PHONES jack: Stereo 1/4-inch phone type
CTL2,3/EXP2 jack
USB COMPUTER port: USB Type-C®
Bluetooth® ADAPTOR connector: Dedicated connector
DC IN jack
Power Supply: AC adaptor
Current Draw: 600 mA
Power consumption when in OFF mode (when the power automatically turns off): 0.0 W
Accessories: AC adaptor (PSB-1U + AC Cord Set)
Owner's manual
Leaflet "USING THE UNIT SAFELY"
Options (sold separately): Footswitch: FS-5U, FS-5L, FS-6, FS-7
Expression Pedal: EV-30, FV-500L, FV-500H, Roland EV-5
Bluetooth® Audio MIDI Dual Adaptor (Model BT-DUAL)
Wireless MIDI Expression Pedal: EV-1-WL
Wireless Foot Switch: FS-1-WL
Size and Weight
Width: 300 mm
11-13/16 inches
Depth: 183 mm
7-3/16 inches
Height: 74 mm
2-15/16 inches
Maximum height: 96 mm
3-3/4 inches
Weight: 2.2 kg
4 lbs 14 oz
